XP50-hf Hazardous Location Spray Package, Cart, 4:1 Mix Ratio, Hoppers, Solvent Pump, Heaters, XTR Gun 573404

In stock
SKU
573404
$70,170.00
Quick Overview
Two-component spraying made easy and affordable.

All in-stock items will ship within 5-7 days. Any items affected by continuing supply chain issues will receive notifications.

Two-component spraying made easy and affordable. The XP-hf system combines the XP50 Sprayers with the powerful XL 10000 air motor. Combining these two technologies, you get more flow - getting jobs done faster and with less wear and tear. Flexible options for mix ratio, pressure and flow rate – choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That’s because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

For higher-volume protective coatings.

  • Reduced material waste
  • No more throwing away unused mixed material at the end of the day
  • Save money by using less clean-up solvent
  • Consistent material quality - no more guesswork or human error in measuring materials
  • Easy to operate - minimal training required
  • Reduced maintenance costs
  • Rated for 5000 psi (345 bar) to handle viscous materials and long hose lengths
More Information
Maximum Working Pressure (psi)5000
Maximum Operating Temperature (F)130
Maximum Fluid Temperature (F)160
Hose Length (ft)35
Air Inlet Size (in)1
Fluid Inlet Size (in)37987
Fluid Outlet Size (in)43832
Maximum Air Consumption (SCFM)60 scfm/gpm at 100 psi
Maximum Air Inlet Pressure (psi)100
Maximum Hose Length (ft)300
Maximum Spray Pressure (psi)5000
Overall Depth (in)52
Overall Height (in)62
Overall Width (in)35
Weight (lb)665
Maximum Working Pressure (bar)344
Maximum Operating Temperature (C)54
Maximum Fluid Temperature (C)71
Hose Length (m)10.7
Maximum Working Pressure (kPa)34400
Overall Height (cm)157.5
Overall Height (mm)1575
Overall Depth (cm)132.1
Overall Depth (mm)1321
Overall Width (cm)88.9
Overall Width (mm)889
Weight (kg)302
Maximum Flow Rate (L/min)14.38
Maximum Air Inlet Pressure (bar)6.9
Maximum Air Inlet Pressure (kPa)690
Maximum Hose Length (m)91.4
Maximum Spray Pressure (bar)344
Maximum Spray Pressure (kPa)34400
